20-24kV
PT handcart
Product parameters:
· Indoor switchgear installation
· Three phase three wire
· Rated voltage: 22kV, 24kV
· Voltage transformer specification depends on PT.
· Installation type: Draw-out type
· Standard: IEC, ANSI, GB
· Type name: UN-HCPT-22
General
This is draw-out hand cart PT, it can made by 3 PT as ‘Y-Y’ connection or two PT as ‘D-D’ start connection.
hand cart use VS1 type suitable for draw-out type cabinet.
Standard
All UNISUN Electric breaker are in conformity with IEC standards, and recommendations IEC60694、IEC6227-100. Breakers in conformity with specific country standards can also be supplied. (IEEE, GB).
Specification data sheet
Type | Voltage ratio(kV) | Accuracy class and rated output(VA) | Limit output (VA) | ||
0.2 | 0.5 | 1 | |||
JDZ10-22 | 22/0.1 | 15 | 30 | 50 | 150 |
JDZ10-24 | 24/0.1 | 15 | 30 | 50 | 150 |
Type | Voltage ratio(kV) | Accuracy class and rated output (VA) | Residual Voltage winding | Limit output (VA) | |||
0.2 | 0.5 | 1 | 3 | 6P | |||
JDZX10-22 | 22/√3/0.1/√3/0.1/3 | 15 | 30 | 60 | 100 | 100 | 150 |
JDZX10-24 | 24/√3/0.1/√3/0.1/3 | 15 | 30 | 60 | 100 | 100 | 150 |
- Products can be customized by customer requirements, above data is standard data, customized data please contact us.
Overall dimension
- Products can be customized by customer requirements, above dimension may change, correct dimension please contact us.
Waiting for your enquiry!
